Old Sep 05, 2012, 08:32 AM
Emress
sirbow2's Avatar
United States, SD, Rapid City
Joined Nov 2011
1,936 Posts
Quote:
Originally Posted by Skewp View Post
My moddest multirotor evolution collection

those look sorta like those crappy hk wood frames. how does it hold up?
sirbow2 is offline Find More Posts by sirbow2
Reply With Quote
Sign up now
to remove ads between posts
Old Sep 05, 2012, 08:39 AM
In progress...
Skewp's Avatar
Estonia, Tartu County, Tartu
Joined Jul 2012
215 Posts
Quote:
Originally Posted by sirbow2 View Post
those look sorta like those crappy hk wood frames. how does it hold up?
These are all custom made plywood frames, one of a kind. Never had a problem with them, quite light and durable.
Skewp is offline Find More Posts by Skewp
Reply With Quote
Old Sep 05, 2012, 08:51 AM
Out of helis, sanity returning
Tallahassee, FL
Joined Feb 2009
2,146 Posts
Quote:
Originally Posted by Skewp View Post
My moddest multirotor evolution collection

That's a sweet looking frame on your octo- the quad too. You must have access to a laser cutter.

Can we see some close-ups of those plywood frames?

Rick
2400RDR is online now Find More Posts by 2400RDR
Reply With Quote
Old Sep 05, 2012, 09:16 AM
In progress...
Skewp's Avatar
Estonia, Tartu County, Tartu
Joined Jul 2012
215 Posts
Quote:
Originally Posted by 2400RDR View Post
That's a sweet looking frame on your octo- the quad too. You must have access to a laser cutter.

Can we see some close-ups of those plywood frames?

Rick
Yes, You are correct. All those plywood frames are laser cut from AutoCAD models. I cannot give any close-ups at the moment but I can say a few words about the quad frame. It is made for Turnigy Plush 25A ESC's, RcTimer 750 kV motors and for any 45x45mm flight controller + HK Quad Power Board. There is a special spot for ESC's in the arm that keeps them locked in one place. In the center there is enough space for a 45x45mm power board and flight controller (with Nylon spacers). Motor mounting holes are made so that every motor's wires are faced to the center of the quad. M2M distance is 76 cm. Landing gear is high enough to mount a 5000 mAh battery on the bottom. These is a total of 4 screws used (and no glue).
Skewp is offline Find More Posts by Skewp
Reply With Quote
Old Sep 05, 2012, 05:54 PM
Registered User
United States, MA, Swansea
Joined Oct 2009
195 Posts
Well I got my quad together and love it, but It's a little big and heavy. We had a break in the rain today so I took it out to fly and had what I think is an issue with the rx dropping signal mid flight (humidity?), so it ended up falling from way up flat upside down and killed my kk2 lcd screen, though it still works fine.

I am going to try out a MWC board again and cut down the arms. I think there will be substantial weight savings by chopping down the arms a good 3" or so. AUW was 959g. I also killed a bearing in one motor so it's down for now till Monday. Can't wait to fly it after I go through it again.
WhiteFox50 is offline Find More Posts by WhiteFox50
Reply With Quote
Old Sep 07, 2012, 06:23 AM
Registered User
United States, SC, Ridge Spring
Joined May 2012
113 Posts
I'm working on this one. The frame is basically complete, and is built with 1/4 plywood and 3/4x3/4" pine. I'm using HK600 landing gear and a power distribution board. The electronics are ordered, and I'll post pics of the finished product when they get here.

Boykintom is offline Find More Posts by Boykintom
Reply With Quote
Old Sep 07, 2012, 12:11 PM
Chad
TheOne420's Avatar
United States, CA, Cathedral City
Joined Dec 2010
1,945 Posts
My first atempt at a tricopter

used dji arms and made a custom frame and yaw mount for it.
flies great just need to practice a little more
TheOne420 is online now Find More Posts by TheOne420
Last edited by TheOne420; Sep 08, 2012 at 01:06 AM.
Reply With Quote
Old Sep 07, 2012, 06:21 PM
Registered User
eyesonsky's Avatar
Switzerland
Joined Jul 2010
346 Posts
Quote:
Originally Posted by thepelell View Post
foldable H quad, built with spare alu squares, 5mm plywood as plates. 60cm mtm distance.
Emax Gt2215/09 motors, flashed esc, 9x4.5 apc props, 4s lipo, AQ50 Pro flight board.

As many other here this DIY Quad is fine.

I am also adept of H-Quad http://www.rcgroups.com/forums/showthread.php?t=1727528
eyesonsky is offline Find More Posts by eyesonsky
Reply With Quote
Old Sep 07, 2012, 08:22 PM
Registered User
Joined Aug 2012
18 Posts
Just sharing my 500 I quad

Electronics : All DJI
Frame 1"X2 Alu channel
Arms 1/2" x 1" Alu channel
hirobo landing gear

Arms are detachable
Still have to work on better battery mount




Short flight test, camera hard mounted no post process video stabilization.
Quad test flight (1 min 21 sec)
elaz is offline Find More Posts by elaz
Reply With Quote
Old Sep 07, 2012, 08:41 PM
Registered User
eyesonsky's Avatar
Switzerland
Joined Jul 2010
346 Posts
Quote:
Originally Posted by elaz View Post
Just sharing my 500 I quad

Electronics : All DJI
Frame 1"X2 Alu channel
Arms 1/2" x 1" Alu channel
hirobo landing gear

Arms are detachable
Still have to work on better battery mount
One QuadH more

Share it your one also here http://www.rcgroups.com/forums/showthread.php?t=1727528

Happy to see the H shape is growing. Simple and works well.
eyesonsky is offline Find More Posts by eyesonsky
Reply With Quote
Old Sep 07, 2012, 10:39 PM
Registered User
Joined Nov 2008
118 Posts
Quote:
Originally Posted by elaz View Post
Just sharing my 500 I quad

Electronics : All DJI
Frame 1"X2 Alu channel
Arms 1/2" x 1" Alu channel
hirobo landing gear

Arms are detachable
Still have to work on better battery mount
What's the weight of that frame? I'm really liking the looks of it.
giek2000 is offline Find More Posts by giek2000
Reply With Quote
Old Sep 08, 2012, 03:18 AM
Registered User
Joined Aug 2012
18 Posts
Quote:
Originally Posted by eyesonsky View Post
One QuadH more

Share it your one also here http://www.rcgroups.com/forums/showthread.php?t=1727528

Happy to see the H shape is growing. Simple and works well.
Quote:
Originally Posted by giek2000 View Post
What's the weight of that frame? I'm really liking the looks of it.
Thanks, weight of Alu body and arms is 250grams
elaz is offline Find More Posts by elaz
Reply With Quote
Old Sep 08, 2012, 07:02 AM
The Engineer
prodriverex's Avatar
Singapore
Joined Dec 2009
621 Posts
Here's my humble built using scratch Al rod..


Too heavy to fly nevertheless..

rated 600gm thrust motor each and 4S 3450mAh pack..

Back to drawing board now with version 2 using CF.. yah no longer using scratch CF.. brand new..
prodriverex is offline Find More Posts by prodriverex
RCG Plus Member
Latest blog entry: Gimball Drone
Reply With Quote
Old Sep 08, 2012, 07:42 AM
Stop me before I build again!
United States, NY, Albany
Joined Sep 2012
1,320 Posts
Quote:
Originally Posted by prodriverex View Post
Too heavy to fly nevertheless..

rated 600gm thrust motor each and 4S 3450mAh pack..

Back to drawing board now with version 2 using CF.. yah no longer using scratch CF.. brand new..
I think it's got more rolling hardware than my office chair, why not try and lose some of that first before giving up on the Al?
brontide is offline Find More Posts by brontide
Reply With Quote
Old Sep 08, 2012, 07:59 AM
The Engineer
prodriverex's Avatar
Singapore
Joined Dec 2009
621 Posts
Quote:
Originally Posted by brontide View Post
I think it's got more rolling hardware than my office chair, why not try and lose some of that first before giving up on the Al?
haha.. ok sure. lose those overkilling landing gears.. I have that for impact purpose..
prodriverex is offline Find More Posts by prodriverex
RCG Plus Member
Latest blog entry: Gimball Drone
Reply With Quote
